HY178DF Diesel Engine
1.Rated Output:3.4KW/5.0HP 2. Roation Speed:3000rpm 3. Fuel Tank Capacity:3.5L 4. Power-Take-Off: Crankshaft
Product Description
Hongyang HY178DF Diesel engine is one air-cooled single-cylinder direct injection diesel engine is a reliable and efficient power source known for its exceptional performance and durability.
1.Rated Output:3.4KW/5.0HP
2. Roation Speed:3000rpm
3. Fuel Tank Capacity:3.5L
4. Power-Take-Off: Crankshaft
| Model | HY178DF |
|---|---|
| Engine Type | Air Cooled 1 - Cylinder 4 - Stroke Diesel Engine |
| Bore*Stroke（mm） | 78*62 |
| Displacement（CC） | 296 |
| Compression Ratio | 20:01 |
| Rated Output（KW/HP） | 3.7/5.0 |
| Rotation Speed（RPM） | 3000 |
| Fuel Type | 0# or - 10#Light Diesel |
| Fuel Tank Capacity（L） | 3.5 |
| Lube Type | Above CD Grade or SAE10W - 30,15W - 40 |
| Lube Capacity（L） | 1.1 |
| Starting System | F:Manual Starter E:Electric Starter |
| Power - Take - Off | Crankshaft |
| Dimension（LxWxH）（mm） | 480x460x520 |
| Net Weight（Kgs） | F:34 FE:40 |
