HY50DCLE Diesel Water Pump
I. Pump Type：Cast Iron Diesel Water Pump II. Model Variants：HY50DC(L)(E)（L: large fuel tank; E: Electric start） III. Inlet/Outlet Size：50(2") mm(in) IV. Performance Parameters：Max Displacement 30 CBM/H；Max Lift 80 m；Max Suction Head 8 m V. Engine Model：HY178DF/FE VI. Engine Specifications：Air Cooled 1 - Cylinder 4 - Stroke Diesel Engine；Bore*Stroke 78×62 mm；Displacement 296 cc；Compression Ratio 20:01；Rated Power 4.0 Kw；Rotation Speed 3600 RPM VII. Fuel & Tank：Fuel 0# or - 10# Diesel；Fuel T
Product Description
Hongyang HY50DC(L)(E) is a cast iron diesel water pump. It uses an air - cooled 1 - cylinder 4 - stroke diesel engine, with a 50(2") inlet/outlet, 30 CBM/H max displacement, and 80 m max lift, suitable for water - pumping tasks needing high - lift performance.
| Model | HY50DC(L)(E) |
|---|---|
| Type | Cast Iron Diesel Water Pump |
| Inlet/Outlet At Size(mm(in)) | 50(2") |
| Displacement Q.max(CBM/H) | 30 |
| Lift H.max(m) | 80 |
| Max Suction Head(m) | 8 |
| Fuel Tank Capacity(L) | 3.5(L:12.5L) |
| Engine Model | HY178DF/FE |
| Type | Air Cooled 1 - Cylinder 4 - Stroke Diesel Engine |
| Bore*Stroke(mm) | 78x62 |
| Rated Power(Kw) | 4.0 |
| Rotation Speed(RPM) | 3600 |
| Displacement(cc) | 296 |
| Compression Ration | 20:01 |
| Fuel | 0# or - 10# Diesel |
| Net Weight(Kg) | 50(E:65) |
| Packing Size(mm) | 540x460x560(L:540x460x655) |
| Optional | L: large fuel tank E: Electric start |
