HY8500DXE Diesel Generator Set
1. Generator Type：Open Frame Air Cooled Single Cylinder Diesel Generator Set 2. Engine Model：HY192DFE 3. Phase Options：Single Phase (8500DXE) 、Three Phase (8500DXE/3) 4. Power Output：Rate Output 6.0 - 6.5 KW (single phase) 、6.0 - 6.5 KW (three phase) ；Max Output 6.5 - 7.0 KW (single phase) 、6.5 - 7.0 KW (three phase) 5. Engine Specifications：Air Cooled 1 - Cylinder 4 - Stroke Direct Injection Diesel Engine ；Bore*Stroke 92x75 mm ；Displacement 498 cc ；Compression Ratio 19:01
Product Description
| Model | HY8500DXE | HY8500DXE/3 |
|---|---|---|
| Type | Open Frame Air Cooled Single Cylinder Diesel generator Set | |
| Rate Output(KW) | 6.0 | 6.5 | 6.0 | 6.5 |
| Max Output(KW) | 6.5 | 7.0 | 6.5 | 7.0 |
| Frequency(HZ) | 50 | 60 | 50 | 60 |
| Phase No | Single Phase | Three Phase |
| Power Factor | CosØ = 1 | CosØ = 0.8 |
| Excitation Mode | Brush(AVR) | Brush(AVR) |
| Starting Type | X:Manual Starter E:Electric Starter | X:Manual Starter E:Electric Starter |
| Engine Model | HY192DFE | HY192DFE |
| Type | Air Cooled 1 - Cylinder 4 - Stroke Direct Injection Diesel Engine | Air Cooled 1 - Cylinder 4 - Stroke Direct Injection Diesel Engine |
| Bore*Stroke(mm) | 92x75 | 92x75 |
| Displacement(cc) | 498 | 498 |
| Rated Power(KW) | 7.6 | 8.6 | 7.6 | 8.6 |
| Rotation Speed(RPM) | 3000 | 3600 | 3000 | 3600 |
| Compression Ration | 19:01 | 19:01 |
| Lube Type | Above CD Grade or SAE10W - 30,15W - 40 | Above CD Grade or SAE10W - 30,15W - 40 |
| Lube Capacity(L) | 1.65 | 1.65 |
| Fuel | 0# or - 10# Diesel | 0# or - 10# Diesel |
| Net Weight(Kg) | 125 | 125 |
| Gross Weight(Kg) | 130 | 130 |
| Packing Size(mm) | 740x505x640 | 740x505x640 |
