Nitrogen inflator HY-3500/N
H1. High energy carbon molecular sieve BF-220# is adopted and used in manufacturing. 2. Rapid nitrogen generation can meet the requirements for continuous nitrogen filling of vehicle tyres. 3. Compressed air is filtered by high precision device. 4. Input air pressure can be self-adjusted. 5. Standard configuration: portable vacuum device FS401. 6. With standard 70L built-in gas tank.
Product Description
Technical Item | FS - 3500 | FS - 3500N |
---|---|---|
Model | FS - 3500 | FS - 3500N |
Power supply | 220V/50 | 110V/220V/50 - 60Hz |
Power | 40W | 60W |
N₂ Purity | 95 - 99.5% | 95 - 99.5% |
Compressed Air Input Range | 8 - 10Bar/116 - 145Psi | 8 - 10Bar/116 - 145Psi |
N₂ Output | 66L/min | 66L/min |
N₂ Storage Tank | 70L/18.5gal | 70L/18.5gal |
N₂ Output Pressure | 5 - 70psi/0.3 - 5bar, ≤10psi/bar | 5 - 70psi/0.3 - 5bar, ≤10psi/bar |
N.W. | 89Kg | 85Kg |
G.W. | 107Kg | 101Kg |
