Nitrogen inflator HY-3500/N

H1. High energy carbon molecular sieve BF-220# is adopted and used in manufacturing.
2. Rapid nitrogen generation can meet the requirements for continuous nitrogen filling of vehicle tyres.
3. Compressed air is filtered by high precision device.
4. Input air pressure can be self-adjusted.
5. Standard configuration: portable vacuum device FS401.
6. With standard 70L built-in gas tank.
Product Description
Technical ItemFS - 3500FS - 3500N
ModelFS - 3500FS - 3500N
Power supply220V/50110V/220V/50 - 60Hz
Power40W60W
N₂ Purity95 - 99.5%95 - 99.5%
Compressed Air Input Range8 - 10Bar/116 - 145Psi8 - 10Bar/116 - 145Psi
N₂ Output66L/min66L/min
N₂ Storage Tank70L/18.5gal70L/18.5gal
N₂ Output Pressure5 - 70psi/0.3 - 5bar, ≤10psi/bar5 - 70psi/0.3 - 5bar, ≤10psi/bar
N.W.89Kg85Kg
G.W.107Kg101Kg
