HY12DXE Diesel Generator Set
I. Generator Type：Open Frame Silent 2 - Cylinder 4 - Stroke Diesel Generator Set II. Engine Model：HY2V80DE III. Phase Options：Single Phase (HY12DXE) 、Three Phase (HY12DXE/3) IV. Power Output：Rate Output 8.5 - 9.0 KW ；Max Output 9.5 - 10.0 KW V. Engine Specifications：V - Type 2 - Cylinder 4 - Stroke Water Cooled Diesel Engine；Bore*Stroke 2×80×79 mm；Displacement 794 cc；Compression Ratio 20:01；Rated Power 12 - 14 KW (3000/3600 RPM) VI. Lubrication：Lube Type CF15W/40；Lube Capacity 1.5 - 3.3 L
Product Description
Hongyang HY12DXE is an open frame silent 2 - cylinder 4 - stroke diesel generator set. It features low noise, stable power output, and is suitable for various scenarios requiring reliable power supply, such as commercial backup power and small - scale industrial use.
| Model | HY12DXE | HY12DXE/3 |
|---|---|---|
| Type | Open Frame Silent 2 - Cylinder 4 - Stroke Diesel Generator Set | |
| Rate Output(KW) | 8.5 | 9.0 | 8.5 | 9.0 |
| Max Output(KW) | 9.5 | 10.0 | 9.5 | 10.0 |
| Frequency(HZ) | 50 | 60 | 50 | 60 |
| Phase No | Single Phase | Three Phase |
| Power Factor | CosØ = 1 | CosØ = 0.8 |
| Excitation Mode | Brush(AVR) | Brush(AVR) |
| Starting Type | E:Electric Starter | E:Electric Starter |
| Engine Model | HY2V80DE | HY2V80DE |
| Type | V - Type 2 - Cylinder 4 - Stroke Water Cooled Diesel Engine | V - Type 2 - Cylinder 4 - Stroke Water Cooled Diesel Engine |
| Bore*Stroke(mm) | 2*80x79 | 2*80x79 |
| Displacement(cc) | 794 | 794 |
| Rated Power(KW) | 12 | 14 | 12 | 14 |
| Rotation Speed(RPM) | 3000 | 3600 | 3000 | 3600 |
| Compression Ration | 20:01 | 20:01 |
| Lube Type | CF15W/40 | CF15W/40 |
| Lube Capacity(L) | 1.5 - 3.3 | 1.5 - 3.3 |
| Fuel | 0# or - 10# Diesel | 0# or - 10# Diesel |
| Net Weight(Kg) | 205 | 205 |
| Gross Weight(Kg) | 225 | 225 |
| Packing Size(mm) | 1100x700x820 | 1100x700x820 |
