HY12000DXE Diesel Generator Set
I. Generator Type：Open Frame Air Cooled Single Cylinder Diesel Generator Set II. Engine Model：HY1105DFE III. Phase Options：Single Phase (12000DXE) 、Three Phase (12000DXE/3) IV. Power Output：Rate Output 9.0 KW ；Max Output 10.0 KW V. Engine Specifications：Air Cooled 1 - Cylinder 4 - Stroke Direct Injection Diesel Engine ；Bore*Stroke 105×88 mm ；Displacement 762 cc ；Compression Ratio 19:01 ；Rated Power 12.5 KW ；Rotation Speed 3000 RPM VI. Lubrication：Lube Type Above CD Grade or SAE10W - 30, 15W
Product Description
Hongyang HY12000DXE is an open frame air - cooled single - cylinder diesel generator set. It offers robust and stable power output, making it an ideal choice for various power - intensive applications, like large - scale events or industrial backup power needs.
| Model | HY12000DXE | HY12000DXE/3 |
|---|---|---|
| Type | Open Frame Air Cooled Single Cylinder Diesel Generator Set | |
| Rate Output(KW) | 9.0 | 9.0 |
| Max Output(KW) | 10.0 | 10.0 |
| Frequency(HZ) | 50 | 50 |
| Phase No | Single Phase | Three Phase |
| Power Factor | CosØ = 1 | CosØ = 0.8 |
| Excitation Mode | Brush(AVR) | Brush(AVR) |
| Starting Type | X:Manual Starter E:Electric Starter | X:Manual Starter E:Electric Starter |
| Engine Model | HY1105DFE | HY1105DFE |
| Type | Air Cooled 1 - Cylinder 4 - Stroke Direct Injection Diesel Engine | Air Cooled 1 - Cylinder 4 - Stroke Direct Injection Diesel Engine |
| Bore*Stroke(mm) | 105*88 | 105*88 |
| Displacement(cc) | 762 | 762 |
| Rated Power(KW) | 12.5 | 12.5 |
| Rotation Speed(RPM) | 3000 | 3000 |
| Compression Ration | 19:01 | 19:01 |
| Lube Type | Above CD Grade or SAE10W - 30,15W - 40 | Above CD Grade or SAE10W - 30,15W - 40 |
| Lube Capacity(L) | 2.1 | 2.1 |
| Fuel | 0# or - 10# Diesel | 0# or - 10# Diesel |
| Net Weight(Kg) | 160 | 160 |
| Gross Weight(Kg) | 165 | 165 |
| Packing Size(mm) | 810x605x780 | 810x605x780 |
