HY188DFE Diesel Engine
Core Performance: 456CC displacement, 19:01 compression ratio. Output: 6.6/9.0 KW/HP (3000RPM) or 7.5/10 KW/HP (3600RPM). Fuel & Lubrication: Uses 0#/-10# light diesel. 5.5L fuel tank, 1.65L lube (above CD grade). Starting & Power: Manual/electric start. Crankshaft power take - off, fits different equipment. Size & Weight: Dimensions 500x460x555mm. Net weight: F 47Kg, FE 53Kg. Applications: Ideal for generators, agricultural machinery (e.g., small harvesters), construction auxiliary equipmen
Product Description
Hongyang HY188DFE Diesel engine is one air-cooled single-cylinder direct injection diesel engine is a reliable and efficient power source known for its exceptional performance and durability.
1.Rated Output:7.5KW/10HP
2. Roation Speed:3600rpm
3. Fuel Tank Capacity:5.5L
4. Power-Take-Off: Crankshaft
| Model | HY188DFE |
|---|---|
| Engine Type | Air Cooled Single Cylinder 4 - Stroke Direct Injection |
| Bore*Stroke（mm） | 88*75 |
| Displacement（CC） | 456 |
| Compression Ratio | 19:01 |
| Rated Output（KW/HP） | 7.5/10 |
| Rotation Speed（RPM） | 3600 |
| Fuel Type | 0# or - 10#Light Diesel |
| Fuel Tank Capacity（L） | 5.5 |
| Lube Type | Above CD Grade or SAE10W - 30,15W - 40 |
| Lube Capacity（L） | 1.65 |
| Starting System | F:Manual Starter E:Electric Starter |
| Power - Take - Off | Crankshaft |
| Dimension（LxWxH）（mm） | 500x460x555 |
| Net Weight（Kgs） | F:47 FE:53 |
