HY2V92DFE Diesel Engine
Core Performance: 997CC displacement, 19.5:1 compression ratio. Output: 14.8/20.2 KW/HP (3000RPM) or 16/21.8 KW/HP (3600RPM). Fuel & Lubrication: Uses 0#/-10# light diesel. Lube type CF15W/40, capacity 3.8 L. Starting & Power: Electric starter. Crankshaft power-take-off, adaptable to diverse devices. Size & Weight: Dimensions 530x580x530mm, net weight 82 Kgs. Applications: Suited for generators, agricultural machinery (like large tillers), construction auxiliary equipment, etc.
Product Description
Hongyang HY2V92DFE Diesel engine is one air-cooled 2-cylinder direct injection diesel engine is a reliable and efficient power source known for its exceptional performance and durability.
1.Rated Output:14.8KW/20.2HP
2. Roation Speed:3000rpm
3. Fuel Tank Capacity:3.8L
4. Power-Take-Off: Crankshaft
| Model | HY2V92DFE |
|---|---|
| Engine Type | V-Type 2-Cylinder 4-Stroke Air Cooled Diesel Engine |
| Bore*Stroke（mm） | 2*92x75 |
| Displacement（CC） | 997 |
| Compression Ratio | 19.5:1 |
| Rated Output（KW/HP） | 14.8/20.2 | 16/21.8 |
| Rotation Speed（RPM） | 3000 | 3600 |
| Fuel Type | 0# or - 10#Light Diesel |
| Lube Type | CF15W/40 |
| Lube Capacity（L） | 3.8 |
| Starting System | E:Electric Starter |
| Power - Take - Off | Crankshaft |
| Dimension（LxWxH）（mm） | 530x580x530 |
| Net Weight（Kgs） | 82 |
