HY6700DXE Diesel Generator Set
I. Generator Type：Open Frame Air Cooled Single Cylinder Diesel Generator Set II. Engine Model：HY186DFAE III. Phase Options：Single Phase (HY6700DX/XE) 、Three Phase (HY6700DX/XE/3) IV. Power Output：Rate Output 4.5 - 5.0 KW (single phase) 、4.5 - 5.0 KW (three phase) ；Max Output 5.0 - 5.5 KW (single phase) 、5.0 - 5.5 KW (three phase) V. Engine Specifications：Air Cooled 1 - Cylinder 4 - Stroke Direct Injection Diesel Engine ；Bore*Stroke 86x72 mm ；Displacement 418 cc ；Compression Ratio 19:01 VI.
Product Description
Hongyang HY6700DX/XE is an open frame air - cooled single - cylinder diesel generator set, delivering stable power with reliable performance. 1. Rate Output: 4.5KW (50HZ), 5.0KW (60HZ) 2. Max Output: 5.0KW (50HZ), 5.5KW (60HZ) 3. Engine Model: HY186DFAE 4. Rotation Speed: 3000rpm or 3600rpm 5. Fuel: 0# or - 10# Diesel 6. Net Weight: 113Kg 7. Power - Take - Off: Crankshaft
| Model | HY6700DX/XE | HY6700DX/XE/3 |
|---|---|---|
| Type | Open Frame Air Cooled Single Cylinder Diesel Generator Set | |
| Rate Output(KW) | 4.5 | 5.0 | 4.5 | 5.0 |
| Max Output(KW) | 5.0 | 5.5 | 5.0 | 5.5 |
| Frequency(HZ) | 50 | 60 | 50 | 60 |
| Phase No | Single Phase | Three Phase |
| Power Factor | CosØ = 1 | CosØ = 0.8 |
| Excitation Mode | Brush(AVR) | Brush(AVR) |
| Starting Type | X: Manual Starter E:Electric Starter | X: Manual Starter E:Electric Starter |
| Engine Model | HY186DFAE | HY186DFAE |
| Type | Air Cooled 1 - Cylinder 4 - Stroke Direct Injection Diesel Engine | Air Cooled 1 - Cylinder 4 - Stroke Direct Injection Diesel Engine |
| Bore*Stroke(mm) | 86x72 | 86x72 |
| Displacement(cc) | 418 | 418 |
| Rated Power(KW) | 5.8 | 6.6 | 5.8 | 6.6 |
| Rotation Speed(RPM) | 3000 | 3600 | 3000 | 3600 |
| Compression Ration | 19:01 | 19:01 |
| Lube Type | Above CD Grade or SAE10W - 30,15W - 40 | Above CD Grade or SAE10W - 30,15W - 40 |
| Lube Capacity(L) | 1.65 | 1.65 |
| Fuel | 0# or - 10# Diesel | 0# or - 10# Diesel |
| Net Weight(Kg) | 113 | 113 |
| Gross Weight(Kg) | 116 | 116 |
| Packing Size(mm) | 740x505x630 | 740x505x630 |
