HY4000DXE Diesel Generator Set
1. Rate Output: 2.8KW (50HZ), 3.2KW (60HZ) 2. Max Output: 3.0KW (50HZ), 3.5KW (60HZ) 3. Engine Model: HY178DF/FE 4. Rotation Speed: 3000rpm or 3600rpm 5. Fuel: 0# or - 10# Diesel 6. Net Weight: 76Kg 7. Power - Take - Off: Crankshaft
Product Description
Hongyang HY4000DX/XE is an open frame air - cooled single - cylinder diesel generator, a practical and efficient power device with reliable performance. 1. Rate Output: 2.8KW (50HZ), 3.2KW (60HZ) 2. Max Output: 3.0KW (50HZ), 3.5KW (60HZ) 3. Engine Model: HY178DF/FE 4. Rotation Speed: 3000rpm or 3600rpm 5. Fuel: 0# or - 10# Diesel 6. Net Weight: 76Kg 7. Power - Take - Off: Crankshaft
| Model | HY4000DX/XE | HY4000DX/XE/3 |
|---|---|---|
| Type | Open Frame Air Cooled Single Cylinder Diesel Generator | |
| Rate Output(KW) | 2.8 | 3.2 | 2.8 | 3.2 |
| Max Output(KW) | 3.0 | 3.5 | 3.0 | 3.5 |
| Frequency(HZ) | 50 | 60 | 50 | 60 |
| Phase No | Single Phase | Three Phase |
| Power Factor | CosØ = 1 | CosØ = 0.8 |
| Excitation Mode | Brush(AVR) | Brush(AVR) |
| Starting Type | X: Manual Starter E:Electric Starter | X: Manual Starter E:Electric Starter |
| Engine Model | HY178DF/FE | HY178DF/FE |
| Type | Air Cooled 1 - Cylinder 4 - Stroke Direct Injection Diesel Engine | Air Cooled 1 - Cylinder 4 - Stroke Direct Injection Diesel Engine |
| Bore*Stroke(mm) | 78X62 | 78X62 |
| Displacement(cc) | 296 | 296 |
| Rated Power(KW) | 3.7 | 4 | 3.7 | 4 |
| Rotation Speed(RPM) | 3000 | 3600 | 3000 | 3600 |
| Compression Ration | 20:01 | 20:01 |
| Lube Type | Above CD Grade or SAE10W - 30,15W - 40 | Above CD Grade or SAE10W - 30,15W - 40 |
| Lube Capacity(L) | 1.1 | 1.1 |
| Fuel | 0# or - 10# Diesel | 0# or - 10# Diesel |
| Net Weight(Kg) | 76 | 76 |
| Gross Weight(Kg) | 80 | 80 |
| Packing Size(mm) | 700x490x590 | 700x490x590 |
