HY2V88DFE Diesel Engine
Core Performance: 912CC displacement, 20:01 compression ratio. Output: 13.8/18.6 KW/HP (3000RPM) or 14.8/20.2 KW/HP (3600RPM). Fuel & Lubrication: Uses 0#/-10# light diesel. Lube type CF15W/40, capacity 3 L. Starting & Power: Electric starter. Crankshaft power take - off, 适配不同动力需求设备（suitable for equipment with different power requirements）. Size & Weight: Dimensions 530x580x530mm. Net weight 76/86 Kgs. Applications: Ideal for generators, agricultural machinery (e.g., large - scale irrigation
Product Description
Hongyang HY2V88DFE Diesel engine is one V-Type 2-Cylinder 4-Stroke Air Cooled diesel engine is a reliable and efficient power source known for its exceptional performance and durability.
1.Rated Output:13.8KW/18.6HP
2. Roation Speed:3000rpm
3. Fuel Tank Capacity:3L
4. Power-Take-Off: Crankshaft
| Model | HY2V88DFE | |
|---|---|---|
| Engine Type | V-Type 2-Cylinder 4-Stroke Air Cooled Diesel Engine | |
| Bore*Stroke（mm） | 2*88x75 | |
| Displacement（CC） | 912 | |
| Compression Ratio | 20:01 | |
| Rated Output（KW/HP） | 13.8/18.6 | 14.8/20.2 |
| Rotation Speed（RPM） | 3000 | 3600 |
| Fuel Type | 0# or - 10#Light Diesel | |
| Lube Type | CF15W/40 | |
| Lube Capacity（L） | 3 | |
| Starting System | E:Electric Starter | |
| Power - Take - Off | Crankshaft | |
| Dimension（LxWxH）（mm） | 530x580x530 | |
| Net Weight（Kgs） | 76/86 | |
