HY7500DXE Diesel Generator Set
I. Generator Type：Open Frame Air Cooled Single Cylinder Diesel Generator Set II. Engine Model：HY188DFE III. Phase Options：Single Phase (7500DX/XE) 、Three Phase (7500DX/XE/3) IV. Power Output：Rate Output 5.0 - 5.5 KW (single phase) 、5.0 - 5.5 KW (three phase) ；Max Output 5.5 - 6.0 KW (single phase) 、5.5 - 6.0 KW (three phase) V. Engine Specifications：Air Cooled 1 - Cylinder 4 - Stroke Direct Injection Diesel Engine ；Bore*Stroke 88x75 mm ；Displacement 456 cc ；Compression Ratio 19:01 VI. Lubri
Product Description
Hongyang HY7500DX/XE is an open frame air - cooled single - cylinder diesel generator set. It provides stable power output, featuring reliable performance and suitable for various scenarios needing backup or mobile power.
| Model | HY7500DX/XE | HY7500DX/XE/3 |
|---|---|---|
| Type | Open Frame Air Cooled Single Cylinder Diesel Generator Set | |
| Rate Output(KW) | 5.0 | 5.5 | 5.0 | 5.5 |
| Max Output(KW) | 5.5 | 6.0 | 5.5 | 6.0 |
| Frequency(HZ) | 50 | 60 | 50 | 60 |
| Phase No | Single Phase | Three Phase |
| Power Factor | CosØ = 1 | CosØ = 0.8 |
| Excitation Mode | Brush(AVR) | Brush(AVR) |
| Starting Type | X:Manual Starter E:Electric Starter | X:Manual Starter E:Electric Starter |
| Engine Model | HY188DFE | HY188DFE |
| Type | Air Cooled 1 - Cylinder 4 - Stroke Direct Injection Diesel Engine | Air Cooled 1 - Cylinder 4 - Stroke Direct Injection Diesel Engine |
| Bore*Stroke(mm) | 88x75 | 88x75 |
| Displacement(cc) | 456 | 456 |
| Rated Power(KW) | 6.6 | 7.5 | 6.6 | 7.5 |
| Rotation Speed(RPM) | 3000 | 3600 | 3000 | 3600 |
| Compression Ration | 19:01 | 19:01 |
| Lube Type | Above CD Grade or SAE10W - 30,15W - 40 | Above CD Grade or SAE10W - 30,15W - 40 |
| Lube Capacity(L) | 1.65 | 1.65 |
| Fuel | 0# or - 10# Diesel | 0# or - 10# Diesel |
| Net Weight(Kg) | 115 | 115 |
| Gross Weight(Kg) | 118 | 118 |
| Packing Size(mm) | 740x505x630 | 740x505x630 |
