HY80DH Diesel Water Pump

1. Pump Type：High Pressure Diesel Water Pump
2. Model Variants：HY80DH(L)(E)（L: large fuel tank; E: Electric start）
3. Inlet/Outlet Size：80(3") mm(in)
4. Performance Parameters：Max Displacement 40 CBM/H；Max Lift 70 m；Max Suction Head 7 m
5. Engine Model：HY188DF/FE
6. Engine Specifications：Air Cooled 1 - Cylinder 4 - Stroke Diesel Engine；Bore*Stroke 88×75 mm；Displacement 456 cc；Compression Ratio 19:01；Rated Power 7.5 Kw；Rotation Speed 3600 RPM

 Send Email

 Inquiry

Product Description

Model	HY80DH(L)(E)
Type	High Pressure Diesel Water Pump
Inlet/Outlet At Size(mm(in))	80(3")
Displacement Q.max(CBM/H)	40
Lift H.max(m)	70
Max Suction Head(m)	7
Fuel Tank Capacity(L)	5.5(L:12.5L)
Engine Model	HY188DF/FE
Type	Air Cooled 1 - Cylinder 4 - Stroke Diesel Engine
Bore*Stroke(mm)	88x75
Rated Power(Kw)	7.5
Rotation Speed(RPM)	3600
Displacement(cc)	456
Compression Ration	19:01
Fuel	0# or - 10# Diesel
Net Weight(Kg)	75
Packing Size(mm)	650x470x605(L:650x470x700)
Optional	L: large fuel tank E: Electric start
