HY15DXE Diesel Generator Set&Welder
1. Generator Type：Open Frame Silent 2 - Cylinder 4 - Stroke Diesel Generator Set 2. Engine Model：HY292DFE 3. Phase Options：Single Phase (HY15DXE) 、Three Phase (HY15DXE/3) 4. Power Output：Rate Output 11.0 - 11.5 KW ；Max Output 12.0 - 12.5 KW 5. Engine Specifications：In - Line 2 - Cylinder 4 - Stroke Air Cooled Diesel Engine；Bore*Stroke 2×92×75 mm；Displacement 997 cc；Compression Ratio 19.5:01；Rated Power 14 - 15 KW (3000/3600 RPM) 6. Lubrication：Lube Type Above CD Grade or SAE10W - 30, 1
Product Description
| Model | HY15DXE | HY15DXE/3 |
|---|---|---|
| Type | Open Frame Silent 2 - Cylinder 4 - Stroke Diesel generator Set | |
| Rate Output(KW) | 11.0 | 11.5 | 11.0 | 11.5 |
| Max Output(KW) | 12.0 | 12.5 | 12.0 | 12.5 |
| Frequency(HZ) | 50 | 60 | 50 | 60 |
| Phase No | Single Phase | Three Phase |
| Power Factor | CosØ = 1 | CosØ = 0.8 |
| Excitation Mode | Brush(AVR) | Brush(AVR) |
| Starting Type | E:Electric Starter | E:Electric Starter |
| Engine Model | HY292DFE | HY292DFE |
| Type | In - Line 2 - Cylinder 4 - Stroke Air Cooled Diesel Engine | In - Line 2 - Cylinder 4 - Stroke Air Cooled Diesel Engine |
| Bore*Stroke(mm) | 2*92x75 | 2*92x75 |
| Displacement(cc) | 997 | 997 |
| Rated Power(KW) | 14 | 15 | 14 | 15 |
| Rotation Speed(RPM) | 3000 | 3600 | 3000 | 3600 |
| Compression Ration | 19.5:01 | 19.5:01 |
| Lube Type | Above CD Grade or SAE10W - 30,15W - 40 | Above CD Grade or SAE10W - 30,15W - 40 |
| Lube Capacity(L) | 1.8 - 2.8 | 1.8 - 2.8 |
| Fuel | 0# or - 10# Diesel | 0# or - 10# Diesel |
| Net Weight(Kg) | 210 | 210 |
| Gross Weight(Kg) | 230 | 230 |
| Packing Size(mm) | 1000x700x820 | 1000x700x820 |
