HY10000DXE Diesel Generator Set
I. Generator Type：Open Frame Air Cooled Single Cylinder Diesel Generator Set II. Engine Model：HY1100DFE III. Phase Options：Single Phase (10000DXE) 、Three Phase (10000DXE/3) IV. Power Output：Rate Output 7.5 KW ；Max Output 8.0 KW V. Engine Specifications：Air Cooled 1 - Cylinder 4 - Stroke Direct Injection Diesel Engine ；Bore*Stroke 100×84 mm ；Displacement 660 cc ；Compression Ratio 19:01 ；Rated Power 9.6 KW ；Rotation Speed 3000 RPM VI. Lubrication：Lube Type Above CD Grade or SAE10W - 30, 15W -
Product Description
Hongyang HY10000DXE is an open frame air - cooled single - cylinder diesel generator set, providing stable power output. It is known for its high reliability and is suitable for various applications, such as backup power for commercial places or construction sites.
| Model | HY10000DXE | HY10000DXE/3 |
|---|---|---|
| Type | Open Frame Air Cooled Single Cylinder Diesel Generator Set | |
| Rate Output(KW) | 7.5 | 7.5 |
| Max Output(KW) | 8.0 | 8.0 |
| Frequency(HZ) | 50 | 50 |
| Phase No | Single Phase | Three Phase |
| Power Factor | CosØ = 1 | CosØ = 0.8 |
| Excitation Mode | Brush(AVR) | Brush(AVR) |
| Starting Type | Electric Starter | Electric Starter |
| Engine Model | HY1100DFE | HY1100DFE |
| Type | Air Cooled 1 - Cylinder 4 - Stroke Direct Injection Diesel Engine | Air Cooled 1 - Cylinder 4 - Stroke Direct Injection Diesel Engine |
| Bore*Stroke(mm) | 100*84 | 100*84 |
| Displacement(cc) | 660 | 660 |
| Rated Power(KW) | 9.6 | 9.6 |
| Rotation Speed(RPM) | 3000 | 3000 |
| Compression Ration | 19:01 | 19:01 |
| Lube Type | Above CD Grade or SAE10W - 30,15W - 40 | Above CD Grade or SAE10W - 30,15W - 40 |
| Lube Capacity(L) | 1.8 | 1.8 |
| Fuel | 0# or - 10# Diesel | 0# or - 10# Diesel |
| Net Weight(Kg) | 145 | 145 |
| Gross Weight(Kg) | 150 | 150 |
| Packing Size(mm) | 810x605x740 | 810x605x740 |
