HY7500DWE Diesel Generator Set&Welder
I. Generator Type：Single Cylinder Air Cooled Diesel Generator & Welder II. Engine Model：HY188DFE III. Welding Parameters：Rated Welding Current 160 A；Welding Current Regulation Range 50 - 180 A；Welding Work Voltage 25 - 30 V；Welding Load Continuous Ratio 60% IV. Power Output：Rate Output 2.0 KW (50 HZ)、2.2 KW (60 HZ) V. Engine Specifications：Air Cooled Single Cylinder Four Stroke Diesel Engine；Bore*Stroke 88×75 mm；Displacement 456 CC；Compression Ratio 19:01；Rated Power 5.8 KW (3000/3600 RPM)
Product Description
Hongyang HY7500DWE is a single - cylinder air - cooled diesel generator & welder. It integrates power generation and welding functions, suitable for scenarios needing mobile power and welding operations, with reliable performance and multi - purpose use.
| Model | HY7500DWE |
|---|---|
| Type | Single Cylinder Air Cooled Diesel Generator&Welder |
| Rated Welding Current(A) | 160 |
| Welding Current Regulation Range(A) | 50 - 180 |
| Welding Work Voltage(V) | 25 - 30 |
| Welding Load Continuous Ration | 60% |
| Rate Output(KW) | 2.0（50HZ） | 2.2（60HZ） |
| Frequency(HZ) | 50 | 60 |
| Phase No | Single Phase |
| Power Factor | CosØ = 1.0 |
| Excitation Mode | Brush(AVR) |
| Starting Type | X:Manual Starter E:Electric Starter |
| Engine Model | HY188DFE |
| Type | Air Cooled Single Cylinder Four Stroke Diesel Engine |
| Bore*Stroke(mm) | 88x75 |
| Displacement(CC) | 456 |
| Rated Power(KW) | 5.8（3000RPM） | 5.8（3600RPM） |
| Rotation Speed(RPM) | 3000 | 3600 |
| Compression Ration | 19:01 |
| Lube Type | Above CD Grade or SAE10W - 30,15W - 40 |
| Lube Capacity(L) | 1.65 |
| Fuel | 0# or - 10# Diesel |
| Net Weight(Kg) | 115 |
| Gross Weight(Kg) | 120 |
| Packing Size(mm) | 740x505x640 |
